ENGINE TYPE | Horizontal 4 stroke, single cylinder, water cooled, Direct Ignition | |
MAX. POWER | 13 HP@2400 rpm | |
DRY WEIGHT | 125 Kg | |
COOLING SYSTEM | Condenser type thermo siphon cooling system | |
OIL SUMP CAPACITY | 2.8 Litres | |
FUEL CONSUMPTION | 1.1 - 1.2 Litres/Hr | |
AIR CLEANER | Multistage, oil bath type with cyclonic pre-cleaner | |
TYPE | Side drive rotary transmission | |
REVERSE | 2 Speed | |
ROTARY | 2 Speed (Optional 4 Speed) | |
CLUTCH | Multiple plate dry disc | |
WEIGHT | 280 Kg | |
BRAKE | Hand operated internal expanding metallic shoe | |
TILLING WIDTH | 2 feet (600 mm) | |
TILLING DEPTH | 6 inches (150 mm max) | |
NO OF BLADES | 18 NOS (9+9) | |
TYRE SIZE | 6 x 12 6-Ply Rating | |
WHEEL TRACK | 920 mm x 690 mm | |
L X W X h | 2720 mm x 865 x 1210 mm | |
KERB WEIGHT | 405 Kg | |
MAX. TRAVELLING SPEED | 15 Kmph* | |
